A novel differential diagnosis for diffuse cavitating nodules: primary pulmonary plasmacytoma

Abstract

Background

Extramedullary plasmacytoma is a rare monoclonal plasma cell neoplasm that originates from tissues other than the bone marrow and constitutes only 3%–5% of all plasma cell neoplasms. Most cases involve the upper respiratory tract. Extramedullary plasmacytoma involving the lung is extremely rare. Primary pulmonary plasmacytoma is a rare type of extramedullary plasmacytoma, usually presenting with a nodule or mass in hilar region. Literature search has shown very few cases of immunohistochemically confirmed cases of pulmonary plasmacytoma. Diffuse pulmonary infiltration is an unusual presentation.

Case presentation

We report the case of a 56 year old lady with history of cough and breathlessness since one month. Computed Tomography revealed diffusely scattered multiple cavitating nodules and consolidation in both lungs. Computed Tomography guided biopsy of one of the lung nodules was done. Histopathologic examination and immunohistochemistry showed features of pulmonary plasmacytoma .This is an unique case of primary pulmonary plasmacytoma with the rare presentation as diffusely scattered multiple cavitating nodules and consolidation. According to our literature search, primary pulmonary plasmacytoma manifesting as cavitating nodules is being reported for the first time.

Conclusions

Primary pulmonary plasmacytoma should be also be considered in the differential diagnosis of multiple diffusely scattered cavitating lung nodules.

Background

Extramedullary plasmacytoma (EMP) is a monoclonal plasma cell tumour that originates from tissues other than the bone marrow [1]. Most cases (80-90%) involve the nasal and paranasal cavities, nasopharynx, larynx, and upper aerodigestive tract [1, 2]. EMP involving the lung is extremely rare [3, 4].

Primary pulmonary plasmacytoma (PPP) usually presents with a nodule or mass in hilar region [1,2,3,4]. Here we report a case of PPP presenting as diffusely distributed multiple cavitating nodules and consolidation, which is exceedingly rare. The present case is the first report of PPP presenting as diffusely distributed multiple cavitating nodules in both lungs.

Case presentation

A 56 year old lady, non-smoker, without a familial lung cancer history, presented to the respiratory clinic complaining of cough, breathing difficulty since one month. Past medical history, family and psycho-social history were unremarkable. Physical examination showed no abnormalities. A routine laboratory work-up showed increased C- reactive protein with normal blood counts, biochemistry, transaminase level, erythrocyte sedimentation rate and protein studies. Bence Jones protein test in urine was negative after 24 hours.

The chest radiograph showed multifocal diffuse confluent nodular opacities in both lungs and consolidation in bilateral lower zones. High resolution computed tomography scan (HRCT) revealed multiple discrete and confluent solid as well as ground glass nodules diffusely scattered in both lungs, predominantly in lower lobes .Most of the nodules showed central cavitation. (Fig 1a, b, c, d and Fig 2) Patchy consolidation were seen in right middle and bilateral lower lobes (Fig 1c, d and Fig 2). Mild right pleural effusion was noted. No obvious enlarged lymph nodes were found in the mediastinum. No lytic lesions were seen in spine and bony thoracic cage. Visualised both breast parenchyma appear normal. Based on imaging findings, metastases and granulomatous disease were kept as differential diagnosis.

Fig. 1
figure 1

HRCT chest axial sections show a, b Diffusely scattered multiple cavitating nodules in both lungs c, d confluent nodules and consolidation in both lower lobes

Fig. 2
figure 2

HRCT chest coronal section shows diffuse multiple cavitating nodules with consolidation in both lower lobes

CT guided core needle biopsy of one of the lung nodules was done under strict aseptic precautions.

Microscopy on histopathology (Fig 3a) showed features suggestive of small round cell tumor with differential diagnosis as plasmacytoma and neuroendocrine tumor. Immunohistochemistry (Fig 3b) revealed neoplastic plasma cells showing strong diffuse expression of CD138, CD45, vimentin and kappa, focally positive for lambda with kappa:lambda ratio of 8:1. Features were suggestive of plasmacytoma. Bone marrow aspiration showed few plasma cells (<5%) with normal skeletal survey. Hence proved as PPP. The patient received chemotherapy for more than 1.5 years and remains in good general condition.

Fig. 3
figure 3

a Histopathological examination showing diffuse sheets of round to plasmacytoid cells b Immunohistochemistry showing CD 138+

Discussion

Plasmacytoma can be classified into: multiple myeloma (MM), isolated plasmacytoma, extramedullary plasmacytoma (EMP) and plasmablastic sarcoma [5].

MM is a systemic condition with monoclonal proliferation of plasma cells primarily involving the bone marrow. EMP is malignant proliferation of single clone of plasma cells arising outside the bone marrow in soft tissues or an organ and may infiltrate adjacent lymph nodes or cause distant metastasis[1]. EMP commonly arises as a solitary tumor in the upper respiratory tract mostly involving the nasal, oral cavity, paranasal sinuses and nasopharynx [1, 2]. Rarely, EMP arises in the lungs [3, 4]. PPP in the lung is extremely rare, although pulmonary involvement with multiple myeloma is more common. Literature review reveals few cases of PPP and is mostly localised to the hilar region as a solitary nodule or mass [1, 3, 4]. Here we report an unusual case of PPP presenting as diffusely distributed multiple cavitating nodules and consolidation.

In the upper airway, submucosa is the most common location for plasmacytoma due to abundance of plasma cells and continuous antigenic exposure [1]. In the lower airway, plasmacytoma occurs in the tracheobronchial tree, hilum [3] or, rarely, in the lung parenchyma [6].

PPP has no particular sex predilection with a median age of 55 years [3, 4, 7]. Serum M protein or Bence-Jones light chains in urine are negative in EMP [7]. Patients are mostly asymptomatic. Joseph et al reported that that nearly half of the cases are asymptomatic with the rest of them showing non-specific symptoms such as cough, dyspnea, chest pain and fever [3, 4]. Clinically PPP is divided into three stages as follows: stage I: the tumor is confined to the primary site; stage II: the tumor has invaded local lymph nodes; stage III: there are obvious widespread metastases [8]. Our case should be classified as stage I based on this. The radiographic presentation is that of a solitary mass or nodule mostly in hilar areas [4]. Typical HRCT manifestation of PPP are solitary lung nodules or masses localised to the hilar region or the lung parenchyma with a tendency for lower lobes. Nodules or masses are round to ovoid in shape, homogenous in appearance with smooth, well delineated margins and sizes ranging from 1.5-6 cm. Few cases have been reported with the rare presentation of diffuse alveolar consolidation [6, 9,10,11] and it suggests that the tumor cells infiltrate into the lung parenchyma [3, 6, 10].

Horiuchi et al. [6] reported a case of 45-year-old woman with fever and hypoxemia showing bilateral reticulonodular infiltration in lower lobes. Another case was reported by Niitsu et al. [10] of bilateral lung involvement and marked hypergammaglobulinemia in a 71-year-old asymptomatic woman. Lazarevic et al. [9] also reported a case with diffuse bilateral lung opacities in an elderly male.

In the current case, the presentation was unusual with diffusely scattered multiple cavitating nodules and consolidation which was initially misdiagnosed as granulomatous disease or metastases. These findings suggest PPP should be considered in the differential diagnosis of multiple cavitating lung nodules. PPP presenting as single or multiple nodules in the lung is often misdiagnosed as organizing pneumonia, tuberculosis, or lung cancer.

The diagnosis of PPP mainly depends on HPE, while CD138 and CD38 are characteristically positive in plasmacytoma. The pathologic differential diagnoses includes MALT lymphoma with plasma cell differentiation [7].

Differentiation of EMP from MM is based on plasma cell infiltration in lung lesions on HPE for a diagnosis of PPP. Normal bone marrow (lower than 5 % plasma cells with no dyscrasia), normal skeletal survey, no related organ or tissue impairment, and no serum and/or urine M protein has to be confirmed to fulfill the definitive diagnostic criteria for PPP which was true in our case [7].

PPP can potentially progress to multiple myeloma. Because of limited literature and its rarity, management and therapeutic options are variable. Both surgery and radiotherapy are good options because of its presentation as a single pulmonary mass. However, when the pulmonary involvement is diffuse, chemotherapy is best choice [7]. Previous cases with diffuse involvement have been treated with melphalan and prednisolone [6]. Surgical resection can be considered curative if it is complete and follow up is advised. Koss et al reported that overall 2-year and 5-year survival rates were 66% and 40% [4].

Conclusions

PPP is a rare type of EMP with difficulty in diagnosis because of its non-specific imaging features. It usually presents as a nodule or mass in the hilar region. PPP presenting as multiple cavitating nodules and consolidation in both lungs is extremely rare; to our knowledge, no cases have been reported in the literature. We report this case to be aware of this unusual finding which can aid in reducing the incidence of errors and missed diagnosis.

Availability of data and materials

Provided in this case report.

Abbreviations

PPP:

Primary pulmonary plasmacytoma

EMP:

Extramedullary plasmacytoma

HPE:

Histopathological examination

MM:

Multiple Myeloma

HRCT:

High resolution Computed Tomography

CT:

Computed Tomography

References

  1. Wiltshaw E (1976) The natural history of extramedullary plasmacytoma and its relation to solitary myeloma of bone and myelomatosis. Medicine (Baltimore) 55:217–238

    CAS  Article  Google Scholar

  2. Dimopoulos MA, Hamilos G (1976) Solitary bone plasmacytoma and extramedullary plasmacytoma. Curr treat options Oncol. 2002; 3(3):255- 9. 2. Wiltshaw E. the natural history of extramedullary plasmacytoma and its relation to solitary myeloma of bone and myelomatosis. Medicine (Baltimore) 55(3):217–238

    Article  Google Scholar

  3. Joseph G, Pandit M, Korfhage L (1993) Primary pulmonary plasmacytoma. Cancer 71:721–724

    CAS  Article  Google Scholar

  4. Koss MN, Hochholzer L, Moran CA, Frizzera G (1998) Pulmonary plasmacytomas: a clinicopathologic and immunohistochemical study of five cases. Ann Diagn Pathol 2(1):1–11

    CAS  Article  Google Scholar

  5. Fanning SR, Hussain MA, Perez-Zincer F. "Plasmacytoma, extramedullary." E medicine. 2006. https://www.emedicine.com/med/topic2532.htm. Accessed 1 Dec 2021.

  6. Horiuchi T, Hirokawa M, Oyama Y et al (1998) Diffuse pulmonary infiltrates as a roentgenographic manifestation of primary pulmonary plasmacytoma. Am J Med 105(1):72–74

    CAS  Article  Google Scholar

  7. Taheri ZM, Mohammadi F, Karbasi M, Seyfollahi L, Kahkoei S, Ghadiany M, Fayazi N, Mansouri D (2010) Primary pulmonary Plasmacytoma with diffuse alveolar consolidation: a case report. Pathol Res Int Article ID 463465:3. https://doi.org/10.4061/2010/463465

    Article  Google Scholar

  8. Nie S, Peng DC, Gong HH, Ye CL, Nie X, Li HJ et al (2016) Primary pulmonary plasmacytoma: a case report introduction. World J Surg Oncol 14:205. https://doi.org/10.1186/s12957-016-0948-8

    Article  PubMed  PubMed Central  Google Scholar

  9. Lazarevic V, Cemerikic-Martinovic V, Suvajdzic N, Subotic D, Colovic M (2001) Diffuse primary plasmacytoma of the lung. Haematologia (Budap) 31:161–165

    CAS  Article  Google Scholar

  10. Niitsu N, Kohri M, Hayama M et al (2005) Primary pulmonary plasmacytoma involving bilateral lungs and marked hypergammaglobulinemia:differentiation from extranodal marginal zone B-cell lymphoma of mucosa-associated lymphoid tissue. Leuk Res 29(11):1361–1364

    Article  Google Scholar

  11. Kim S-H, Kim TH, Sohn JW, Yoon HJ, Shin DH, Kim IS, Par SS (2012) Primary pulmonary Plasmacytoma presenting as multiple lung nodules. Korean J Intern Med 27:111–113. https://doi.org/10.3904/kjim.2012.27.1.111

    Article  PubMed  PubMed Central  Google Scholar

Download references

Acknowledgements

Not applicable

Funding

Nil.

Author information

Authors and Affiliations

Authors

Contributions

All authors had substantial contributions to the conception of the case report. All authors were active participants in the drafting and revising of the case report. All authors approved the final version of manuscript. All authors agree to be accountable for all aspects of the work. All authors were directly involved in this patient’s care and contributed to the writing and editing of this manuscript. SK, RM researched and wrote the patient background and pulmonary history. HV, SS researched and wrote the abstract and conclusion of the manuscript, captured and arranged the images. SP conceptualized the process; researched, compiled, and wrote the procedure, conclusion, and introduction; and served as the overall editor.

Corresponding author

Correspondence to Shruthi Panduranga.

Ethics declarations

Ethics approval and consent to participate

Ethics has approved this study.

Consent for publication

The authors certify that they have obtained all appropriate patient consent forms. In the form the patient has given her written informed consent for her images and other clinical information to be reported in the journal. The patients understand that their names and initials will not be published and due efforts will be made to conceal their identity, but anonymity cannot be guaranteed.

Competing interests

The authors declare that they have no competing interests.

Additional information

Publisher’s Note

Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.

Rights and permissions

Open Access This article is licensed under a Creative Commons Attribution 4.0 International License, which permits use, sharing, adaptation, distribution and reproduction in any medium or format, as long as you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons licence, and indicate if changes were made. The images or other third party material in this article are included in the article's Creative Commons licence, unless indicated otherwise in a credit line to the material. If material is not included in the article's Creative Commons licence and your intended use is not permitted by statutory regulation or exceeds the permitted use, you will need to obtain permission directly from the copyright holder. To view a copy of this licence, visit http://creativecommons.org/licenses/by/4.0/.

Reprints and Permissions

About this article

Verify currency and authenticity via CrossMark

Cite this article

Panduranga, S., Kade, S., Shivakumar, S. et al. A novel differential diagnosis for diffuse cavitating nodules: primary pulmonary plasmacytoma. Egypt J Bronchol 15, 54 (2021). https://doi.org/10.1186/s43168-021-00101-x

Download citation

  • Received:

  • Accepted:

  • Published:

  • DOI: https://doi.org/10.1186/s43168-021-00101-x

Keywords

  • Pulmonary neoplasms
  • Plasmacytoma
  • Cavitating nodules
  • Diffuse lung nodules
  • Case report
